AMS1117 — 1A Low Dropout Voltage Regulator
Advanced Monolithic Systems, Inc. AMS1117
AMS1117 — 1A Low Dropout Voltage Regulator The AMS1117 is a 1A low-dropout linear voltage regulator from Advanced Monolithic Systems, available in adjustable and fixed (1.5V, 1.8V, 2.5V, 2.85V, 3.3V, 5.0V) versions in SOT-223, TO-252, and SO-8 packages.
AOZ1282CI — 1.2 A Simple Buck Regulator
Alpha & Omega Semiconductor AOZ1282CI
AOZ1282CI — 1.2 A Simple Buck Regulator Alpha & Omega Semiconductor AOZ1282CI EZBuck. 4.5–36 V input, 1.2 A output adjustable down to 0.8 V, 450 kHz PWM, internal 420 mΩ NMOS, SOT23-6L.
AP2112K — 600 mA CMOS LDO Regulator with Enable
Diodes Incorporated AP2112
AP2112K — 600 mA CMOS LDO Regulator with Enable Diodes AP2112. 600 mA CMOS LDO, ±1.5 % accuracy, 2.5–6.0 V input, enable pin, low-quiescent 55 µA, fixed 1.2/1.8/2.5/2.6/3.3 V, SOT25/SOT89-5/SO-8.
AP2114H — 1 A Low-Noise CMOS LDO Regulator with Enable
Diodes Incorporated AP2114
AP2114H — 1 A Low-Noise CMOS LDO Regulator with Enable Diodes AP2114. 1 A CMOS LDO with enable, ±1.5 % accuracy, 450 mV dropout @ 1 A, 30 µVrms noise, 60 µA Iq. 1.2/1.5/1.8/2.5/3.3 V fixed + adjustable. SOT-223 through PSOP-8.
AP63357 — 3.8 V to 32 V, 3.5 A Low-IQ Synchronous Buck
Diodes Incorporated AP63357
AP63357 — 3.8 V to 32 V, 3.5 A Low-IQ Synchronous Buck Diodes AP63357 (V-DFN3020-13). 3.5 A synchronous buck with 74 mΩ HS + 40 mΩ LS MOSFETs, 22 µA IQ PFM mode, 450 kHz FSS for low EMI, 3.8–32 V input.
AS5147 — 14-Bit On-Axis Magnetic Rotary Position Sensor
ams OSRAM AS5147
AS5147 — 14-Bit On-Axis Magnetic Rotary Position Sensor ams OSRAM AS5147. 14-bit absolute / 11-bit incremental magnetic rotary sensor with DAEC™. SPI, ABI, UVW, PWM outputs. TSSOP-14, AEC-Q100 Grade 0 for BLDC motor commutation in EPS/transmission.
ATmega328P — 8-bit AVR Microcontroller
Microchip (formerly Atmel) ATmega328P
ATmega328P — 8-bit AVR Microcontroller Microchip (Atmel) ATmega328P. 8-bit AVR RISC, 32KB flash, 2KB SRAM, 1KB EEPROM, 23 I/O, 10-bit ADC, 20 MHz, 1.8–5.5 V. The core of the Arduino Uno.
BHI360
BHI360 Bosch Sensortec BHI360 programmable, ultra-low-power smart sensor hub with integrated 6-axis IMU (accelerometer + gyroscope), 32-bit Fuser2 MCU, and BSX sensor fusion library. 2.5x3.0mm LGA-20 package, 7.8uA deep sleep, SPI/I2C host interface.
BMA400 — 3-axis Ultra-Low-Power Accelerometer
Bosch Sensortec BMA400
BMA400 — 3-axis Ultra-Low-Power Accelerometer Bosch Sensortec BMA400. 12-bit triaxial accelerometer, ±2g/±4g/±8g/±16g, <14.5µA normal mode. Step counter, activity recognition, tap detection, 1KB FIFO, SPI/I²C. LGA-12 2×2×0.95mm.
BMA456
BMA456 Bosch Sensortec BMA456. 16-bit triaxial MEMS accelerometer for wearables. +/-2g to +/-16g range, 150uA performance / 3.5uA suspend, SPI/I2C, 1KB FIFO, step counter, LGA-12 2x2mm. Standardized datasheet with 10 extracted diagrams.
BMA530
BMA530 Bosch Sensortec BMA530 ultra-small triaxial low-g MEMS accelerometer — 16-bit, +/-2g to +/-16g, SPI/I2C/I3C, 125 uA typ, 1.2x0.8 mm WLCSP
BME688
BME688 Bosch Sensortec BME688 — Digital low power gas, pressure, temperature & humidity sensor with AI
BME690 — 4-in-1 Environmental Sensor with AI Gas Scanner
Bosch Sensortec BME690
BME690 — 4-in-1 Environmental Sensor with AI Gas Scanner Bosch Sensortec BME690 digital low-power temp/humidity/pressure/gas sensor with AI in 3.0x3.0x0.9 mm LGA-8. 1.71-3.6V supply, -40 to +85 °C.
BMI270
BMI270 Bosch Sensortec BMI270. Ultra-low power 6-axis IMU (accel + gyro) for wearables. 16-bit, 685uA typ, I2C/SPI, wrist gestures, OIS support, LGA-14. Standardized datasheet with 15 extracted diagrams.
BMI323
BMI323 Bosch Sensortec BMI323 6-axis IMU — 16-bit accelerometer (±2/4/8/16g) and gyroscope (±125–2000°/s) with on-chip feature engine, SPI/I3C/I2C, 2.5×3.0mm LGA
BMM350 — 3-Axis High-Performance Magnetometer
BMM350 — 3-Axis High-Performance Magnetometer Bosch Sensortec BMM350. TMR-based 3-axis magnetometer, +/-2000 uT range, 190 nT noise, I2C/I3C, 1.28x1.28mm WLCSP. Standardized datasheet with 14 extracted diagrams.
BMP390 — Digital Barometric Pressure Sensor
BMP390 — Digital Barometric Pressure Sensor Bosch Sensortec BMP390. High-performance barometric pressure sensor, 300-1250 hPa, +/-3 Pa relative accuracy, 3.2 uA at 1 Hz, I2C/SPI, 2x2mm LGA-10. Standardized datasheet with 15 extracted diagrams.
BMP581
BMP581 Bosch Sensortec BMP581 — Next-gen barometric pressure sensor with ultra-low noise and power
BMV080
BMV080 Bosch Sensortec BMV080 ultra-mini fanless laser-based particulate matter sensor for PM1, PM2.5, and PM10 measurement
DS
Texas Instruments BQ27441-G1
BQ27441-G1 — Single-Cell Li-Ion Fuel Gauge with Impedance Track Texas Instruments system-side fuel gauge for single-cell Li-Ion batteries. Reports remaining capacity, state-of-charge, and battery voltage over I2C using the patented Impedance Track algorithm. 12-pin VSON, 2.50 x 4.00 mm.
BQ76952 Battery Monitor and Protector
Texas Instruments BQ76952
BQ76952 Battery Monitor and Protector Texas Instruments BQ76952 battery monitor/protector for 3s-16s Li-ion, Li-polymer, and LiFePO4 packs. Exhaustive extraction with full pin table, expanded design guidance, and all 26 figure-bearing datasheet pages captured.
CD74HC4067 — 16-Channel Analog Multiplexer / Demultiplexer
Texas Instruments CD74HC4067
CD74HC4067 — 16-Channel Analog Multiplexer / Demultiplexer TI CD74HC4067. 16-channel bidirectional analog mux/demux, 70 Ω typ R(on), break-before-make, 2–6 V HC or 4.5–5.5 V HCT. 24-pin PDIP/SOIC/SSOP/TSSOP.
CSD18540Q5B — 60 V N-channel Power MOSFET
Texas Instruments CSD18540Q5B
CSD18540Q5B — 60 V N-channel Power MOSFET Texas Instruments CSD18540Q5B: 60 V, N-channel NexFET power MOSFET in SON 5x6 mm. 1.8 mOhm RDS(on) at VGS=10 V, 41 nC total gate charge, 205 A continuous drain current.
ITR-9608 — Slotted Opto-Interrupter (IR LED + NPN Phototransistor)
Zhuhai Dapeng Elec-Tech Co., Ltd. ITR-9608
ITR-9608 — Slotted Opto-Interrupter (IR LED + NPN Phototransistor) Zhuhai Dapeng ITR-9608 is a 4-pin through-hole slotted photo-interrupter pairing an IR928-6c IR LED with a PT928-6c NPN phototransistor on a 5 mm slot. Typical 940 nm emission, 0.4 V max VCE(sat), 15 µs rise/fall. Used for edge/position sensing in mice, scanners, limit switches, and disk drives.
LM555 Timer
LM555 Timer Texas Instruments LM555 timer/oscillator. 4.5–16V, 200mA output, 8-pin SOIC/PDIP/VSSOP. Standardized datasheet with 20 extracted diagrams, electrical characteristics, pin descriptions, and design charts.
P34-RGB05P02N3P1IMA03-CC
Shenzhen H-Great Optoelectronic P34-RGB05P02N3P1IMA03-CC
P34-RGB05P02N3P1IMA03-CC Addressable RGB LED — 3.4x3.3mm PLCC-6, 800Kbps NRZ, 8-bit PWM, 12mA, daisy-chain
RFD22301
RF Digital Corporation RFD22301
RFD22301 Bluetooth 4.0 BLE module — ARM Cortex M0, 15x15mm, on-board antenna, Arduino compatible, CE/FCC certified
SM16825E
Shenzhen Sunmoon Microelectronics SM16825E
SM16825E 5-channel RGBWY constant current LED driver — 10-300mA, 16-bit PWM, RZ protocol, 5-40V, ESOP8
SMI230 — 6DoF Inertial Sensor for Automotive Applications
Robert Bosch GmbH SMI230
SMI230 — 6DoF Inertial Sensor for Automotive Applications Robert Bosch GmbH SMI230. Automotive-grade 6-axis IMU combining 16-bit triaxial accelerometer and gyroscope in LGA-16 package. AEC-Q100 Grade 2, SPI/I2C, 2.4-3.6V. 106-page full datasheet with all 41 figures extracted.
SiR680ADP
Vishay Siliconix SiR680ADP
SiR680ADP N-Channel 80V MOSFET — 2.35mOhm RDS(on), 100A, PowerPAK SO-8, TrenchFET Gen IV, sync rect/DC-DC
VL53L8CX -- 8x8 Multizone Time-of-Flight Sensor
VL53L8CX -- 8x8 Multizone Time-of-Flight Sensor STMicroelectronics VL53L8CX. 8x8 multizone ToF ranging sensor, 400cm range, 65-degree FoV, I2C/SPI, 940nm VCSEL. Standardized datasheet with 21 extracted diagrams.
XBLW ULN2003AB
Xinbole (XBLW) ULN2003AB
XBLW ULN2003AB Seven-channel Darlington transistor array — 500mA/ch, 50V, TTL/CMOS input, integrated clamp diodes, DIP-16/SOP-16
iCE40HX1K — 1.28K-Cell Low-Power Non-Volatile FPGA
Lattice Semiconductor iCE40HX1K
iCE40HX1K — 1.28K-Cell Low-Power Non-Volatile FPGA Lattice iCE40HX1K — 1,280-cell ultra-low-power FPGA. Three matched symbol+footprint pairs with clean custom-rendered PNGs, interactive viewers, per-artifact provenance.
