The LM36011 is an ultra-small LED flash driver that provides a high level of adjustability. It can produce up to 1.5 A of LED flash current or up to 376 mA of torch current. This is all done from an accurately I2C programmable current source without the need of a pre-regulated voltage. This molecule is prebroken out to act as a DUT in a chip qualification test, enabling rapid environmental and electronic testing with included nested footprints for on-device functional validation.

LM36011 LED Flash Driver Qual-Ready

Type: Adom Molecule Creator: adonis Version: v1 Category: motor_driver Availability: 100%, 24/7

Overview

The LM36011 is an ultra-small LED flash driver that provides a high level of adjustability. It can produce up to 1.5 A of LED flash current or up to 376 mA of torch current. This is all done from an accurately I2C programmable current source without the need of a pre-regulated voltage. This molecule is prebroken out to act as a DUT in a chip qualification test, enabling rapid environmental and electronic testing with included nested footprints for on-device functional validation.

Science Drivers

• chip qualification

NSF Relevance

This molecule serves as an example of a chip qualification coupon within the Adom Factory, demonstrating how discrete devices can be mounted, instrumented, and stress-tested under controlled electrical and environmental conditions. It provides a standardized platform for validating device performance and reliability throughout automated qualification workflows.

Integration Guide

To use LM36011 LED Flash Driver Qual-Ready in your design:

1. Download the schematic symbol and PCB footprint from the Files section
2. Import into your EDA tool (KiCad or Fusion 360 / EAGLE)
3. Place the molecule in your schematic and connect the interface pins
4. Use the 3D model (.glb) for mechanical fit verification

Design Notes

Board design files (.brd, .sch, .f3d) are available for modification and reference.
